Product Advantage
Extreme Strength for High-Pressure Environments
Engineered with 2,500+ MPa tensile strength, this fabric withstands up to 10 bar pressure in RO/UF systems—3x stronger than traditional polyester supports. Its 3D interlaced structure prevents filter media collapse, ensuring uniform flow distribution and 20% lower pressure drop (ASTM D638 compliant).
Broad Chemical & Thermal Resistance
Resists pH 2–13 and 500 ppm chlorine, ideal for harsh industrial wastewater. Withstands temperatures up to 120°C, outperforming polypropylene supports in steam-sterilized systems (ISO 22282 certified). Reduces maintenance by 40% in chemical-intensive applications like oil refineries.
Optimized Filtration Efficiency
Features 95% void volume and 0.5–2 mm thickness to retain ≥5 μm particles while enhancing flux by 15%. Its low surface roughness (Ra ≤1.2 μm) minimizes particle adhesion, extending filter lifespan by 30% compared to non-woven alternatives.
Eco-Friendly & Cost-Effective
Composed of 100% recyclable polymers, it cuts waste by 35% vs. non-recyclable supports. Lightweight (80–150 g/m²) yet durable, retaining 98% structural integrity after 5,000 hours of continuous use (ASTM D638), reducing replacement frequency and operational costs.
Customizable for Diverse Systems
Offers grammage (60–200 g/m²) and thickness options to match MF, UF, or RO membrane requirements. Adopts antibacterial coatings for food & beverage filtration, meeting FDA 21 CFR 177.1630 for contact with drinking water.
Technical Parameters
| Parameter | Specification | Test Standard |
| Material Composition | Dual-component polymers (PP/PE， PET/PA) | ISO 13934-1 |
| Fiber Type | Coarse denier filaments (≥15 denier) | IASTMD3379 |
| Grammage | 60-200 g/m²(customizable) | ISO 9073-1 |
| Thickness | 0.5-2 mm (adjustable for MF/UF/RO systems) | ISO 5084 |
| Tensile Strength | 2，500-3，500 MPa (longitudinal)/2，000-2，800 MPa (transverse) | IASTMD638 |
| Void Volume | 95% (optimized for particle retention) | IASTMD4422 |
| Pressure Resistance | ≤10 bar (high-pressure RO/UF systems) | ISO 22282 |
| Temperature Resistance | -20℃ to 120℃ (dry)， -10℃ to 90℃(wet) | IASTMD648 |
| Chemical Resistance | pH2-13，≤500ppm chlorine， resistant to common industrial solvents (e.g.,ethanol，acetone) | ASTMD543 |
| Surface Roughness | Ra ≤1.2 um (minimizes particle adhesion) | ISO 4287 |
| Particle Retention | ≥5 um (dependent on grammage/thickness) | ISO 16232-10 |
| Flow Rate Enhancement | Reduces pressure drop by 20% vs. traditional supports | ISO 5167-1 |
| Eco-Friendly Features | 100% recyclable， 35% waste reduction vs. non-recyclable materials | |
| Certifications | ISO 22282 (water quality)， FDA 21 CFR 177.1630 (food contact)， ISO 14001(environmental) | |
| Application Fields | RO/UF/MF membranes， industrial wastewater， oil & gas filtration， power generation |
Product Uses
Reverse Osmosis (RO) Systems
Used as a structural base in RO membranes for desalination and industrial water purification. Withstands 10 bar pressure and 500 ppm chlorine, preventing media collapse while reducing pressure drop by 20%. Ideal for oil refineries and power plants requiring high-purity water (ISO 22282 compliant).
Ultrafiltration (UF) & Microfiltration (MF)
Supports UF/MF membranes in wastewater recycling, retaining ≥5 μm particles with 95% void volume. Its pH 2–13 resistance suits harsh industrial effluents, extending filter life by 30% in manufacturing and chemical plants.
Oil & Gas Filtration
Integrated into offshore and onshore filtration systems to handle oily wastewater and drilling fluids. Resists solvents like acetone and ethanol, while 120°C heat tolerance ensures performance in high-temperature refinery processes. Reduces maintenance by 40% in corrosive environments.
Power Generation Cooling Systems
Protects condenser water filters in thermal power plants, resisting scaling and microbial growth. Lightweight (80–150 g/m²) yet durable, it maintains 98% structural integrity after 5,000 hours of continuous use, minimizing downtime in coal and gas-fired facilities.
Food & Beverage Filtration
Certifed to FDA 21 CFR 177.1630 for direct food contact, it supports sterile filtration in breweries and dairies. Antibacterial coatings prevent biofilm formation, ensuring compliance with NSF/ANSI 61 for drinking water applications (e.g., bottled water production).
Metal Finishing & Electroplating
Used in wastewater treatment for heavy metal removal, withstanding strong acids (pH 2) and alkalis (pH 13). Its low surface roughness (Ra ≤1.2 μm) reduces particle adhesion, improving recovery of valuable metals like nickel and copper.
FAQ
Q: Can this fabric withstand high-pressure industrial filtration systems?
A: Yes! With 2,500+ MPa tensile strength and 10 bar pressure resistance, it prevents media collapse in RO/UF systems, reducing pressure drop by 20% (ASTM D638 compliant).
Q: How does it perform in chemically harsh environments?
A: Resists pH 2–13 and 500 ppm chlorine, ideal for wastewater and oil refinery applications. Withstands temperatures up to 120°C, outlasting traditional supports by 40% (ISO 22282 certified).
Q: Is it eco-friendly and cost-effective?
A: Yes! Composed of 100% recyclable polymers, it cuts waste by 35% vs. non-recyclable materials. Retains 98% integrity after 5,000 hours of use, reducing replacement frequency and costs.
Q: Can it be customized for specific filtration needs?
A: Absolutely! Offers 60–200 g/m² grammage and 0.5–2 mm thickness for MF/UF/RO systems. Adds antibacterial coatings for food-grade applications (FDA 21 CFR 177.1630 compliant).
Q: How does it compare to traditional filter supports?
A: 3x stronger with 95% void volume, enhancing particle retention (≥5 μm) and flux by 15%. Its low roughness (Ra ≤1.2 μm) minimizes fouling, extending filter lifespan by 30%.
