Product Advantage
Constructed from 90% post-consumer recycled polyester (derived from 12 plastic bottles/m²), it reduces carbon emissions by 1.2kg/m². RoHS/REACH-compliant and 100% recyclable, it supports LEED/BREEAM certifications, positioning it as a sustainable choice for green building projects.
Features a microporous structure (≤5μm pores) enabling ≥2000g/m²/24h WVTR for vapor diffusion while blocking liquid water. This reduces condensation risks by 70% in cold storage facilities, maintaining dry environments even at -20℃ to 150℃ temperature extremes.
Boasts ≥200N/cm tensile strength and 40% better tear resistance than traditional materials. Its 0.35-1.2mm thickness withstands 10 million cycles of vibration, making it ideal for industrial machinery-heavy environments like automotive plants.
Combines with coatings for IPX8 waterproofing, offers 15dB noise reduction, and provides 0.8(m²·K)/W thermal resistance. Lightweight (75-200g/m²) yet UV-resistant, it cuts roof load by 25% and supports solar panel installations.
Technical Parameters
| Parameter | Specification | Description |
| Material Composition | 80-95% recycled polyester + 5-20% high-strength polyester filaments | Derived from plastic bottles, 90% post-consumer recycled content |
| Thickness | 0.35-1.2mm | Customizable for different structural requirements |
| Width | Up to 1.45m | Reduces seams by 60% for efficient installation |
| Weight | 75-200g/m² | Lightweight design minimizes roof load by 25% |
| Tensile Strength | ≥200N/cm (MD) | Withstands structural stress and vibrations in industrial environments |
| Tear Strength | ≥80N (TD) | 40% higher than traditional materials for long-term durability |
| Puncture Resistance | ≥150N | Resists damage from sharp objects during installation |
| Water Vapor Transmission Rate (WVTR) | ≥2000g/m²/24h | Prevents condensation while allowing vapor diffusion |
| Waterproof Rating | IPX8 (when combined with coatings) | Blocks liquid water penetration |
| Temperature Range | -20℃ to 150℃ | Maintains performance in extreme weather conditions |
| Flame Retardancy | CFR 1633 certified, LOl ≥32% | Self-extinguishing, no toxic smoke or molten drops |
| UV Resistance | 500 hours QUV exposure | Resists degradation from sunlight for outdoor applications |
| Chemical Resistance | Acid/alkali resistant (pH 2-12) | Suitable for corrosive industrial environments |
| Eco-Certifications | RoHS, REACH, 100% recyclable | Recycled content ≥90%, supports LEED/BREEAM certifications |
| Service Life | 20+ years | Long-term reliability with minimal maintenance |
Product Uses
With CFR 1633 flame-retardant certification and 150℃ heat resistance, the fabric withstands sparks and high temperatures in welding workshops. Its ≥80N tear strength resists structural stress, reducing roof leaks by 92% in Volkswagen’s automotive assembly plants when combined with IPX8 coatings.
The breathable moisture barrier (≥2000g/m²/24h WVTR) prevents condensation in cold storage, while its 75-200g/m² lightweight design cuts roof load by 18%. JD.com’s Asia No.1 Warehouse extended insulation lifespan from 8 to 25 years, saving ¥350,000 annual maintenance costs.
The 1.45m wide format integrates seamlessly with solar panels, and its 0.8(m²·K)/W thermal resistance improves PV efficiency by 2.3%. SPIC’s 50MW solar project reduced system costs by ¥12/W when combined with EVA films.
Its seamless 1.45m width speeds up installation by 50%, while 100% recyclability supports sustainable recovery. During the 2021 Henan Flood Relief Project, 50,000m² of moisture barriers were deployed in 7 days, earning Ministry of Housing recognition.
FAQ
Q1: Is the fabric fire-safe for industrial applications?
A: Yes! It holds CFR 1633 flame-retardant certification (LOI ≥32%), self-extinguishing with no toxic smoke or molten drops. Suitable for chemical plants and warehouses, it maintains integrity at 150°C for 500+ hours.
Q2: How does it prevent condensation in cold storage?
A: The microporous structure (≤5μm pores) allows vapor diffusion (≥2000g/m²/24h WVTR) while blocking liquid water. This balances humidity and reduces condensation risks by 70% in 冷链 facilities.
Q3: What environmental benefits does it offer?
A: Made from 90% recycled polyester (from plastic bottles), it’s 100% recyclable and RoHS-compliant. Reduces carbon footprint by 1.2kg/m², supporting LEED and BREEAM certifications.
Q4: Can it withstand heavy machinery vibrations?
A: Absolutely! With ≥200N/cm tensile strength and 40% better tear resistance than traditional materials, it resists structural stress and vibrations in manufacturing plants.
Q5: How long does the fabric last?
A: Offers 20+ years service life with proper installation. Lightweight (75-200g/m²) and UV-resistant, it minimizes maintenance costs by 30% compared to conventional solutions.
